Mitsubishi GT1555-QTBD
The Mitsubishi GT1555-QTBD operator interface is designed for efficient human-machine interaction. This device features a 5.7-inch TFT color display capable of showing 65536 colors with a resolution of 320 × 240 dots.
This Mitsubishi GT1555-QTBD is supplied brand new by PartLogic for machine control, process visibility, operator input, production monitoring and industrial automation applications. It forms part of our Industrial automation > Hmi > Touch panels range and is referenced internally as PartLogic SKU PL26805680681.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Mitsubishi |
| Product Line | GOT1000 |
| Part Number | GT1555-QTBD |
| Weight | 12.00 lbs (5.44 kg) |
| Product Description | Operator Interface |
| Display Character | 16-dot standard font: 40 characters 30 lines (2-byte characters), 12-dot standard font: 53 characters 40 lines (2-byte characters) |
| Display Color | 65536 colors |
| Display Angle | Left/right: 70 degrees, Top: 70 degrees, Bottom: 50 degrees (Horizontal format) |
| Touch Panel | Matrix resistive film |
| Key Size | Minimum 16 x 16 dots (per key) |
| Power Supply | 24 VDC |
| Memory | C drive for Flash memory (Internal), for storing project data (3Mbytes) and OS |
| Built-in Interface | RS-232, USB, CF card, option function card, and extension unit |
| External Dimensions (W x H x D) | 167 x 135 x 56 mm |
| Mass | 1.1 kg (Excluding mounting fixtures) |
| Display Type | TFT color liquid crystal |
| Screen Size | 5.7 |
| Display Resolution | 320 × 240 [dots] |
| Display Size (W x H) | 115 x 86 mm |
| Brand | Mitsubishi |
