Mitsubishi FX2N-16MT-001
The Mitsubishi FX2N-16MT-001 I,O module is engineered for seamless integration into automation systems. It features 16 I,O points, consisting of 8 digital inputs and 8 digital outputs, and adjustable response times to suit various operational needs.
This Mitsubishi FX2N-16MT-001 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Programmable logic controllers range and is referenced internally as PartLogic SKU PL26805661889.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Mitsubishi |
| Product Type | I/O Module |
| Product Line | FX Series |
| Part Number | FX2N-16MT-001 |
| Weight | 3.00 lbs (1.36 kg) |
| Total I/O Points | 16 (8 Digital Inputs + 8 Digital Outputs) |
| Response Time for Input | ~10ms, adjustable from 50µs to 60ms |
| Minimum Current for Input ON | 4.5mA |
| Maximum Current for Input OFF | 1.5mA |
| Isolation for Input Circuit | Photocoupler |
| Input Status Display | LED lights up when input is active |
| Voltage for Input Signal | 24V DC ±10% |
| Current per Input | 7mA |
| Output Configuration | Transistor Output |
| Output Switching Speed | ON \u003C 0.2ms; OFF \u003C 0.2ms |
| Leakage Current for Output | Maximum 0.1mA |
| Inductive Load Capability per Output | 12W at 24V DC |
| Resistive Load Capability per Output | 0.5A per point, 0.8A across 4 points |
| Voltage Range for Output Load | 5V–30V DC |
| Brand | Mitsubishi |
