Keyence IL-300
Vishay IL300 linear optocoupler, DIP-8, 5.3kV isolation.
This Keyence IL-300 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Displacement sensors > Laser displacement sensors range and is referenced internally as PartLogic SKU PL26989909444.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Ambient Temperature Range High | 100 °C |
| Bandwidth | 200 kHz |
| Case/Package | DIP |
| Contact Plating | Tin |
| Current Transfer Ratio | 1.1 % |
| Fall Time | 1.75 µs |
| Forward Current | 10 mA |
| Forward Voltage | 1.4 V |
| Height | 4.55 mm |
| Input Current | 10 mA |
| Isolation Voltage | 4.42 kV |
| Lead Free | Lead Free |
| Length | 10.16 mm |
| Max Input Current | 60 mA |
| Max Junction Temperature (Tj) | 125 °C |
| Max Operating Temperature | 100 °C |
| Max Output Voltage | 500 mV |
| Max Power Dissipation | 210 mW |
| Min Operating Temperature | -55 °C |
| Mount | PCB, Through Hole |
| Number of Channels | 1 |
| Number of Elements | 1 |
| Number of Pins | 8 |
| Output Current per Channel | 70 µA |
| Output Voltage | 500 mV |
| Power Dissipation | 150 mW |
| Radiation Hardening | No |
| REACH SVHC | Unknown |
| Reverse Breakdown Voltage | 5 V |
| Reverse Voltage | 5 V |
| Reverse Voltage (DC) | 5 V |
| Rise Time | 1.75 µs |
| RoHS | Compliant |
| Schedule B | 8541408000, 8541408000|8541408000, 8541408000|8541408000|8541408000, 8541408000|8541408000|8541408000|8541408000 |
| Voltage | 5 V |
| Width | 6.6 mm |
