IFM MFS200
Fuse, ptc reset, 30v, 4.4A; holding current:4.4A; tripping current:4.4A; initial resistance max:0.06ohm; operating voltage:30v; series:multifuse; ptc
This IFM MFS200 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Magnetic range and is referenced internally as PartLogic SKU PL26801443399.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Approvals | CSA, TUV, UL |
| Case/Package | Axial |
| Height | 1.1 mm |
| Hold Current | 2 A |
| Length | 23.4 mm |
| Max Current Rating | 100 A |
| Max Operating Temperature | 85 °C |
| Min Operating Temperature | -40 °C |
| Mount | Surface Mount |
| Number of Terminals | 2 |
| Operating Supply Voltage | 30 V |
| Packaging | Bulk |
| Power Dissipation | 1.9 W |
| Radiation Hardening | No |
| Resistance | 60 mΩ |
| RoHS | Compliant |
| Schedule B | 8536100040, 8536100040|8536100040|8536100040|8536100040|8536100040 |
| Terminal Material | Nickel |
| Termination | Axial |
| Time to Trip | 4 s |
| Trip Current | 4.4 A |
| Voltage Rating | 30 V |
| Voltage Rating (DC) | 30 V |
| Width | 11 mm |
