Honeywell BZE6-2RN
Limit switch, bze6 series, spdt, limit switch actuator: plunger, 15A, 480VAC, operating force max:6.67n, 500mA
This Honeywell BZE6-2RN is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Limit switches range and is referenced internally as PartLogic SKU PL26805285542.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Approvals | CSA, UL |
| Case/Package | 600 |
| Current Rating | 15 A |
| Depth | 77.2 mm |
| Differential Travel | 15 mm |
| Height | 112.7 mm |
| Housing Material | Zinc |
| Length | 25.4 mm |
| Max Current Rating | 15 A |
| Max Operating Temperature | 71 °C |
| Max Voltage Rating (AC) | 600 V |
| Max Voltage Rating (DC) | 250 V |
| Min Operating Temperature | -32 °C |
| Mount | Chassis Mount, Screw |
| Number of Poles | 1 |
| Number of Positions | 2 |
| Orientation | Straight |
| Overtravel | 556 mm |
| Pretravel | 478 mm |
| Ratings | IP54, IP66, Water Resistant |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Switch Function | On-Mom |
| Termination | Conduit |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 125 V |
| Voltage Rating (DC) | 125 V |
| Width | 44.4 mm |
