Honeywell 914CE2-3
Limit switch, microswitch, top roller plunger, spdt, 1 NO, 5A, 250VAC, 28VDC, IP66,67,69, direct replacement for 914ce2-3k
This Honeywell 914CE2-3 is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Limit switches range and is referenced internally as PartLogic SKU PL26805289576.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Approvals | CSA, IEC, UL |
| Contact Plating | Silver |
| Depth | 44 mm |
| Differential Travel | 1 mm |
| Housing Material | Zinc |
| Lead Free | Lead Free |
| Length | 40 mm |
| Max Current Rating | 5 A |
| Max Operating Temperature | 105 °C |
| Mechanical Life | 10 Mcycles |
| Min Operating Temperature | 0 °C |
| Mount | Brackets, Chassis Mount |
| Number of Channels | 1 |
| Number of Poles | 1 |
| Number of Positions | 2 |
| Operating Force | 118 N |
| Operating Position | 28.4988 mm |
| Overtravel | 30 mm |
| Pretravel | 508 µm |
| Ratings | Dust Tight, IP66, IP68, Water Resistant |
| REACH SVHC | Unknown |
| RoHS | Compliant |
| Switch Function | On-Mom |
| Termination | Cable |
| Throw Configuration | SPDT |
| Voltage Rating (AC) | 250 V |
| Voltage Rating (DC) | 28 V |
| Width | 16 mm |
