FANUC IC660BBD110
The GE Fanuc IC660BBD110 is an intelligent 16-point discrete input block. This module is a 115VAC discrete input block, with operating voltage range of 93-132VAC, 47-63 Hz. This module directly communicates to the processor or communication adapter via the Genius protocol. This module supports right side up or upside-down orientation.
This FANUC IC660BBD110 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules range and is referenced internally as PartLogic SKU PL26821477781.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | GE Fanuc Emerson |
| Product Type | Discrete Input Block |
| Product Line | Genius I-O |
| Part Number | IC660BBD110 |
| Weight | 3.25 lbs (1.47 kg) |
| Series | Genius Block I/O |
| Module type | Discrete input block I/O |
| Input Voltage Range | 93-132 VAC |
| Nominal Input voltage | 115VAC |
| Input Current (mA) | 80mA max. block current plus 200mA max. input circuit current |
| Number of points | Sixteen (16) |
| Input off state, input on state | Programmable threshold (25% to 85%) |
| Input shorted wire | Fixed 10%-90% thresholds |
| Selectable input filter times | 10 to 100ms in 10ms increments |
| Input diagnostics | Open Wire, Short Circuit |
| Input to ground or serial bus Isolation | 1500V |
| Number of Inputs | 16 |
| Number of Outputs | None |
| Voltage Type | AC |
| Operating Temperature | 32 to 140 degrees Fahrenheit |
| Storage Temperature | -40 to 212 degrees Fahrenheit |
| Fault Detection | Short Wire Faults and Open Wire Faults |
| Brand | GE Fanuc Emerson |
