FANUC A06B-0113-B175#0008
The FANUC A06B-0113-B175#0008 is a reliable servo motor designed for various industrial applications. This component features a rated power of 2.0 kW and operates efficiently at a rated speed of 3,000 RPM. It has capabilities for maximum torque up to 19.1 Nm, making it suitable for demanding tasks.
This FANUC A06B-0113-B175#0008 is supplied brand new by PartLogic for machine drive systems, motion control, equipment maintenance, replacement motor sourcing and industrial automation applications. It forms part of our Industrial automation > Motors > Servo motors range and is referenced internally as PartLogic SKU PL26805312030.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | FANUC |
| Product Line | A06B |
| Part Number | A06B-0113-B175#0008 |
| UPC | 641752892804 |
| Weight | 3.13 lbs (1.42 kg) |
| Rated Power | 2.0 kW |
| Rated Torque | 6.37 Nm |
| Maximum Torque | 19.1 Nm |
| Rated Speed | 3,000 RPM |
| Maximum Speed | 6,000 RPM |
| Voltage | 200 V |
| Rated Current | 9.3 A |
| Insulation Class | F |
| Cooling Type | Non-cooled (natural convection) |
| Encoder Type | Absolute pulse coder |
| Shaft Type | Straight shaft with keyway |
| Mounting Type | Flange-mounted |
| Protection Rating | IP65 |
| Ambient Temperature | 0°C to 40°C (operational) |
| Brand | FANUC |
