Delta FFB0824SH
Fan, tubeaxial, 80x38mm, 7 blade, 24VDC, 2 wire
This Delta FFB0824SH is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Cooling > Fans > Axial range and is referenced internally as PartLogic SKU PL26882375628.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Airflow | 68.5 CFM |
| Approvals | CE, CSA, UL, VDE |
| Bearing Type | Ball |
| Case/Package | Axial |
| Current Rating | 340 mA |
| Depth | 80 mm |
| Housing Material | Plastic |
| Length | 80 mm |
| Max Operating Temperature | 158 °C |
| Max Power Dissipation | 8.16 W |
| Min Operating Temperature | 14 °C |
| Power Rating | 8.16 W |
| RoHS | Compliant |
| RPM | 4900 RPM |
| Termination | 3 Wire Leads |
| Voltage Rating | 24 V |
| Weight | 170.097139 g |
| Width | 38 mm |
