Delta AFC0948DE
92×92×38mm 48V DC Fan with Speed Sensor (TACH) and PWM
This Delta AFC0948DE is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Cooling > Fans > Axial range and is referenced internally as PartLogic SKU PL27189553333.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Airflow | 159.4 CFM |
| Approvals | CE, TUV, UL |
| Bearing Type | Ball |
| Case/Package | Axial |
| Current Rating | 600 mA |
| Height | 92 mm |
| Housing Material | Plastic |
| Lead Free | Lead Free |
| Length | 92 mm |
| Life (Hours) | 70000 hours |
| Max Operating Temperature | 149 °C |
| Max Power Dissipation | 28.8 W |
| Min Operating Temperature | -40 °C |
| Power Rating | 28.8 W |
| RoHS | Compliant |
| RPM | 7500 RPM |
| Termination | Wire Leads |
| Weight | 259.908428 g |
| Width | 38 mm |
