Delta AFB1212HHE
Axial fan, 120mm, 12v, 120.07cfm, 44dba; supply voltage V DC:12v; fan frame type:square; fan frame size:120mm; external depth:38mm; bearing type:ball bearing; air flow - cfm:120.07cfm; noise rating:44dba; power rating:5.52W rohs compliant: yes
This Delta AFB1212HHE is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Cooling > Fans > Axial range and is referenced internally as PartLogic SKU PL26870044624.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Airflow | 120.1 CFM |
| Approvals | CE, CSA, UL, VDE |
| Bearing Type | Ball |
| Current Rating | 460 mA |
| Max Operating Temperature | 140 °C |
| Max Power Dissipation | 5.52 W |
| Min Operating Temperature | 14 °C |
| RoHS | Compliant |
| RPM | 2900 RPM |
| Termination | 3 Wire Leads |
| Weight | 255.826097 g |
| Width | 38 mm |
