Delta AFB0624VHC
Axial fan, 60mm, 24VDC, 27.72cfm, 38dba; supply voltage V DC:24v; fan frame type:square; fan frame size:60mm; external depth:13mm; bearing type:ball bearing; air flow - cfm:27.72cfm; noise rating:38dba; power rating:2.88W; ip rating:-rohs compliant: yes
This Delta AFB0624VHC is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Cooling > Fans > Axial range and is referenced internally as PartLogic SKU PL26890274602.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Airflow | 27.7 CFM |
| Bearing Type | Ball |
| Case/Package | Axial |
| Current Rating | 120 mA |
| Life (Hours) | 70000 hours |
| Max Operating Temperature | 158 °C |
| Max Power Dissipation | 2.88 W |
| Min Operating Temperature | 14 °C |
| RoHS | Compliant |
| RPM | 5400 RPM |
| Schedule B | 8414599080 |
| Termination | 3 Wire Leads |
| Weight | 33.565835 g |
