Delta AFB0512HHB
Delta AFB Series DC Axial Fan, 50x50x15mm, 12V, 16.24 CFM, 36 dBA, Ball Bearing
This Delta AFB0512HHB is supplied brand new by PartLogic for machinery automation, electrical maintenance, replacement part sourcing and industrial repair applications. It forms part of our Industrial automation > Cooling > Fans > Axial range and is referenced internally as PartLogic SKU PL26817963447.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Airflow | 16.2 CFM |
| Bearing Type | Ball |
| Case/Package | Axial |
| Current Rating | 130 mA |
| Depth | 50 mm |
| Housing Material | Plastic |
| Length | 50 mm |
| Life (Hours) | 70000 hours |
| Max Operating Temperature | 158 °C |
| Max Power Dissipation | 1.56 W |
| Min Operating Temperature | 14 °C |
| Power Rating | 1.56 W |
| RoHS | Compliant |
| RPM | 6400 RPM |
| Schedule B | 8414599080 |
| Termination | 3 Wire Leads |
| Voltage Rating | 12 V |
| Weight | 32.205058 g |
