Beijer Electronics PWS6600T-S
The Beijer PWS6600T-S falls within the PWS series and features a robust design ranging from -10°C to +60°C for operational temperatures. This panel supports CE, FCC, and UL certifications, making it suitable for a variety of applications.
This Beijer Electronics PWS6600T-S is supplied brand new by PartLogic for machine control, process visibility, operator input, production monitoring and industrial automation applications. It forms part of our Industrial automation > Hmi > Operator panels range and is referenced internally as PartLogic SKU PL26805656168.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Beijer |
| Product Line | PWS |
| Part Number | PWS6600T-S |
| Approval Certifications | CE, FCC, UL |
| Ambient Temperature | Operating: -10°C to +60°C; Storage: 0°C to +50°C |
| Serial Communication | Number of serial ports: 1 Port 9-pin DSUB / 1 Port 25-pin DSUB |
| Serial Port 1 | RS232/RS485 |
| Serial Port 2 | RS232/RS422/RS485 |
| Shock | 10 G, 11 ms 3 times in each direction of X, Y, and Z axes |
| Vibration | 0.5 mm displacement, 10-55 Hz, 2 hours per X, Y, and Z-axis directions |
| Sealing Front | IP65 |
| Humidity | 20 - 90% RH non-condensed |
| Mechanical Size | 195.0 x 145.0 x 59.1 mm |
| Housing Material | Plastic, Gray |
| Number of Touches | 1 million finger touch operations |
| Display Type | Color TFT LCD |
| Backlight Brightness | 400 cd/m² |
| Backlight Lifetime | 50,000 hours |
| Touch Type | Resistive |
| Cut-out Size | 185.8 x 135.8 mm |
| Brand | Beijer |
