Beckhoff KL1501
DIGITAL INPUT TERMINAL, UP,DOWN COUNTER, 24 VDC, 100 KHZ, 32 BIT COUNTER DEPTH
This Beckhoff KL1501 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Bus terminal range and is referenced internally as PartLogic SKU PL26805667289.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Model | KL1501 |
| Function | 1-channel digital input counter |
| Nominal voltage | 24 V DC (-15%/+20%) |
| Counting frequency | Max. 100 kHz (2 kHz switching up/down) |
| Counter depth | 32 bit (single) or 2 × 16 bit (dual) |
| Signal voltage “0” | -3…+5 V (EN 61131-2, type 1) |
| Signal voltage “1” | 15…30 V (EN 61131-2, type 1) |
| Input current | Typ. 5 mA (EN 61131-2, type 1) |
| Outputs | 24 V/0.5 A per channel, short-circuit proof |
| Electrical isolation | 500 V (K-bus/field potential) |
| Current consumption (K-bus) | Typ. 50 mA |
| Current load power contacts | 10 A |
| Dimensions | 12 mm × 100 mm × 68 mm |
| Weight | Approx. 50 g |
| Material | Polycarbonate |
| Installation | 35 mm DIN rail, EN 60715 with lock |
| Protection rating | IP20 |
| Operating temperature | -25…+60 °C |
| Storage temperature | -40…+85 °C |
| Relative humidity | 95%, no condensation |
| Vibration/Shock | EN 60068-2-6 / EN 60068-2-27 |
| EMC | EN 61000-6-2 / EN 61000-6-4 |
| Approvals/Markings | CE, CCC, UL, ATEX, IECEx, cFMus |
