Banner T30UXDA
Banner T30UXDA Ultrasonic Proximity Sensor, 30mm Rectangular, Diffuse, 200-1000mm, NPN,PNP NO,NC, Cable
This Banner T30UXDA is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Ultrasonic range and is referenced internally as PartLogic SKU PL26805591027.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Case/Package | 100 |
| Diameter | 40 mm |
| Housing Material | PBT |
| Length | 51.1 mm |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | -40 °C |
| Operating Supply Voltage | 30 V |
| Ratings | IP67 |
| Response Time | 45 ms |
| RoHS | Compliant |
| Switching Current | 40 mA |
| Switching Frequency | 224 kHz |
| Termination | Cable |
