Banner SM312LV
Photoelectric sensor, mini beam series industry standard, retro, 5 m range, 10-30VDC, 1 npn , 1 pnp, bipolar, 2 m cable, 25618
This Banner SM312LV is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Photoelectric range and is referenced internally as PartLogic SKU PL26842907928.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Approvals | CE, CSA, UL |
| Body Material | ABS |
| Cable Length | 2 m |
| Contact Current Rating | 150 mA |
| Height | 30.7 mm |
| Housing Material | Polyester |
| Max Operating Temperature | 70 °C |
| Max Output Current | 150 mA |
| Max Supply Voltage (DC) | 30 V |
| Min Operating Temperature | -20 °C |
| Min Supply Voltage (DC) | 10 V |
| Number of Pins | 4 |
| Output Current | 150 mA |
| Ratings | IP67 |
| REACH SVHC | No |
| Response Time | 1 ms |
| RoHS | Compliant |
| Sensing Distance | 5 m |
| Turn-On Delay Time | 100 ms |
