Banner SM312DQD
Banner Engineering SM312DQD Photoelectric Sensor, Diffuse, 380mm, NPN,PNP
This Banner SM312DQD is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Photoelectric range and is referenced internally as PartLogic SKU PL26801437777.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Approvals | CE, CSA, UL |
| Body Material | PBT, Polyester, Thermoplastic |
| Height | 30.7 mm |
| Housing Material | Polyester |
| Length | 53.3 mm |
| Max Operating Temperature | 70 °C |
| Max Output Current | 150 mA |
| Max Supply Voltage (DC) | 30 V |
| Min Operating Temperature | -20 °C |
| Min Supply Voltage (DC) | 10 V |
| Number of Pins | 4 |
| Output Current | 150 mA |
| Ratings | IP67 |
| REACH SVHC | No |
| Response Time | 1 ms |
| RoHS | Compliant |
| Sensing Method | Infrared (IR) |
| Turn-On Delay Time | 100 ms |
| Width | 12.2 mm |
