Allen Bradley 802T-ATP
The 802T-ATP is a robust metal plug-in oiltight limit switch from Allen Bradley's 802T series. It features a rotary lever arm actuator and metal body, designed for variable industrial applications requiring reliable signaling.
This Allen Bradley 802T-ATP is supplied brand new by PartLogic for industrial automation, machine feedback, position detection, measurement, monitoring and maintenance applications. It forms part of our Industrial automation > Sensors > Limit switches range and is referenced internally as PartLogic SKU PL26941226984.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Metal Plug-In Oiltight Limit Switch |
| Product Line | 802T Limit Switches |
| Part Number | 802T-ATP |
| Weight | 1.25 lbs (0.57 kg) |
| Actuator | Rotary Lever Arm |
| Body Material | Metal |
| Contact Operation | Snap Acting, Standard Contacts |
| Maximum Travel | Up to approximately 90° for lever |
| Number of Switching Circuits | 4-circuit (often 2 NO + 2 NC) |
| Travel to Operate Contacts (Nominal) | 13° |
| Travel to Reset Contacts (Maximum) | 7° |
| NEMA Type | NEMA Type 4 and 13 |
| Rated Current (AC) | 10 A |
| Protection Rating | IP67 |
| Conduit Entry | ½″-14 NPT conduit opening |
| Torque to Operate | 0.45 N·m |
| Wire Connection Style | Screw terminals |
| Operating Temperature | −18 °C to +110 °C |
| Brand | Allen Bradley |
