Allen Bradley 700-CF220D
The 700-CF220D from Allen Bradley is a reliable IEC Industrial Control Relay tailored for use in various industrial applications. It features a control coil voltage rating of 110 volts AC (50 Hz) and 120 volts AC (60 Hz).
This Allen Bradley 700-CF220D is supplied brand new by PartLogic for control panels, machine wiring, power distribution, industrial maintenance and replacement applications. It forms part of our Industrial automation > Electrical components > Contactors range and is referenced internally as PartLogic SKU PL27206692334.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | IEC Industrial Control Relay (Contactor-Style) |
| Product Line | Bulletin 700 |
| Part Number | 700-CF220D |
| Weight | 0.38 lbs (0.17 kg) |
| Coil Voltage (Control) | 110 volts AC (50 Hz) / 120 V AC (60 Hz) |
| Fixed Contact Configuration | 4-Pole Base Unit: 3 Normally Open (N.O.) + 1 Normally Closed (N.C.) |
| Terminal Type | Screw Terminals |
| Operational Current | 10 amps at AC-15 rating |
| Thermal Current | 25 amps (AC-1 rating) |
| Maximum Rated Voltage | 690 volts AC |
| Total Pole Capacity (Max) | 10 Poles (Base unit + up to 6 auxiliary contacts can be added) |
| Contact Type | Mechanically linked NO/NC contacts |
| Mounting | 35 mm DIN Rail or Screw/Panel Mount |
| Design Feature | Includes mechanically linked contacts as standard |
| Width | 45 millimeters |
| Brand | Allen Bradley |
