Allen Bradley 5069-OBV8S
The Allen-Bradley 5069-OBV8S is a Compact 5000 Digital 8-point Safety Sourcing Output Module. This module features Eight (8) output channels that operates at voltage range of 17.5-32VDC. It provides output current of 1 A per channel. This module is rated SIL CL3, PLe, Cat. 4 with safety reaction time of 4.5 ms .
This Allen Bradley 5069-OBV8S is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Safety > Compact 5000 range and is referenced internally as PartLogic SKU PL26942697724.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | CompactLogix 5069 |
| Part Number | 5069-OBV8S |
| UPC | 889508477145 |
| Weight | 0.50 lbs (0.23 kg) |
| Series | Compact 5000 I/O |
| Module Type | Safety DC Output module |
| No. of Outputs | Eight (8) DC safety output channels |
| Output Voltage signal, nominal | 24VDC |
| Output Voltage Signal range | 17.5-32VDC |
| Output current rating | 1:00 AM |
| Safety Integrity Level | SIL CL3, PLe, Cat. 4 |
| Safety reaction time (SRT) | 4.5 ms |
| Pulse width, min | 400 µs |
| No. of output groups | Two (2) |
| Field power loss detection | Yes (per point) |
| Reverse voltage protection | Yes |
| Type | Output module |
| Output type | 8-point output |
| Output voltage | 8-32 Volts DC |
| Output rating | 1 Ampere per channel |
| Isolation voltage | 250 Volts |
| Operating temperature | 0 to 50 degrees Celsius |
| Orientation | Horizontal or Vertical |
| Wire type | Copper |
| Structure | Conformal coating |
| Brand | Allen Bradley |
