Allen Bradley 2711PC-T6C20D
The Allen-Bradley,Rockwell Automation 2711PC-T6C20D terminal is a compact interface terminal in the Panelview Plus 6 Compact terminal series. It is designed to fit into smaller installation spaces than standard Allen-Bradley Panelview Plus terminals are usually able to. The 2711PC-T6C20D compact interface terminal’s 6-inch touchscreen supports color graphics. Its input power rating is 24 Volts DC. The 2711PC-T6C20D compact interface terminal’s memory includes 512 MB of nonvolatile memory and 256 MB of RAM.
This Allen Bradley 2711PC-T6C20D is supplied brand new by PartLogic for machine control, process visibility, operator input, production monitoring and industrial automation applications. It forms part of our Industrial automation > Hmi > Panelview plus range and is referenced internally as PartLogic SKU PL26935405649.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | Panelviews |
| Product Line | Panelview Plus 6 Compact |
| Part Number | 2711PC-T6C20D |
| UPC | 612598766079 |
| Weight | 2.06 lbs (0.94 kg) |
| Display Size | 5.5 in. |
| Product Family | PanelView Plus Graphic Terminals |
| Sub Category | PanelView Plus Compact Terminal |
| Operator Input | Touch |
| Display Type | Color active matrix, thin-film transistor (TFT) liquid crystal display (LCD) |
| Display Area | 112 x 84 mm (4.4 x 3.3 in.) |
| Resolution | 320 x 240 |
| Touch interface | Analog resistive |
| Operating force | 10…110 g |
| Actuating lifespan | 1 million presses |
| Terminal Memory | Series A: 5 MB Series B: 10 MB |
| Communication ports | Ethernet, RS-232, 1 USB |
| Power Supply Input Voltage range | 18-30VDC |
| Power Consumption | 25 W max (1.0 A at 24V DC) |
| No. of displays | 25 |
| No. of alarm messages | 200 |
| Display Color | Color |
| Input Type | Touchscreen |
| Communication | Ethernet and RS-232 |
| Input Power | 24V DC |
| Memory | 512 MB nonvolatile memory and 256 MB RAM |
| Enclosure Type | NEMA/UL Type 12, 13, 4X (indoor use only), and IEC IP66 |
| Brand | Allen Bradley |
