Allen Bradley 2711P-T12C4D8
The Allen-Bradley 2711P-T12C4D8 is a Panelview Plus 6 1250 Operator Terminal. This operator terminal is powered by an external 18-30VDC supply voltage and has a 12.1-inch colored display with embedded Ethernet, RS232, and Two (2) USB communication port. This operator terminal has a touchscreen input interface.
This Allen Bradley 2711P-T12C4D8 is supplied brand new by PartLogic for machine control, process visibility, operator input, production monitoring and industrial automation applications. It forms part of our Industrial automation > Hmi > Panelview plus range and is referenced internally as PartLogic SKU PL26939396698.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | PanelView Plus 6 1200 Operator Terminals |
| Product Line | Panelview Plus 6 |
| Part Number | 2711P-T12C4D8 |
| UPC | 612598876723 |
| Weight | 6.00 lbs (2.72 kg) |
| Display Area | 246 x 184 mm (9.7 x 7.2 in.) |
| Backlight | CCFL, 50,000 hours min at 25 ° C (77 °F), field replaceable |
| Display Size | 12.1 inches |
| Display Type | Color active-matrix TFT |
| Product Family | PanelView Plus 6 Operator Terminals |
| Operator Input | Touch |
| Lifecycle status | End of life |
| Touch | 1 million presses |
| Internal memory | 512MB Flash Memory / 512 MB Random Access Memory |
| Integrated ports | Ethernet, RS-232, 2 USB host |
| Input Voltage range | 18-30VDC |
| Input Type | Touchscreen |
| Input Power | 18 to 32 Volts DC |
| Memory | 512 MB RAM |
| Communication Cable | 2711-NC13 |
| Series | Series A and Series B |
| Communication | Ethernet and RS-232 |
| Display Resolution | 800 x 600, 18-bit color graphics |
| Real Time Clock (Battery) | 2711P-RY2032 (CR2032) |
| Product Dimensions | 11.12 x 14.30 x 2.18 in. (282 x 363 x 55 mm) |
| Cutout Dimensions | 10.11 x 13.29 in. (257 x 338 mm) |
| Logic Module | 2711P-RP8D |
| Display Module | 2711P-RDT12C |
| Brand | Allen Bradley |
