Allen Bradley 25-ENC-1
The Allen-Bradley 25-ENC-1 is an incremental encoder input. This encoder is compatible with the PowerFlex 525 adjustable Frequency AC Drive. This encoder card sources 5 or 12 Volt power and accepts 5, 12 or 24 Volts in single ended of differential input wiring configuration. This encoder is used as a feedback device for Closed loop PM control and may be configured up to 1024 Pulser Per Revolution (PPR).
This Allen Bradley 25-ENC-1 is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives > Powerflex 520 range and is referenced internally as PartLogic SKU PL26931623510.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | Drives |
| Product Line | PowerFlex 525 |
| Part Number | 25-ENC-1 |
| UPC | 884951990098 |
| Weight | 0.25 lbs (0.11 kg) |
| Description | PowerFlex 525 drive incremental encoder |
| Current rating | 250 milliamps |
| Voltage rating | 12.0 Volts DC |
| Encoder type | Quadrature (dual-channel) incremental encoder |
| Product Family | PowerFlex 527 Adjustable Frequency AC Drive |
| Control Method | Closed loop velocity vector control |
| Signal Wiring | Single ended / Differential |
| Voltage source selection | via DIP switch |
| Removal and Insertion under power | not supported |
| Minimum wire size | 0.08 mm2 (28 AWG) |
| Maximum Wire size | 2.08 mm2 (14 AWG) |
| tightening Torque | 0.18...0.22 Nm (1.56...1.9 lb-in) |
| Network type | Ethernet/IP |
| Quadrature rating | +/-27 degrees at 25 degrees Celsius |
| Output control | Voltage DIP switches |
| Brand | Allen Bradley |
