Allen Bradley 22-COMM-E
The Allen-Bradley 20-COMM-E is an Ethernet I,P communication adapter that is compatible for use with PowerFlex 4, 40 and 400 series drives. This adapter directly attached to the drive’s communication adapter slot and provides EtherNet I,P connectivity with data communication rates of 10 Mbps Full Duplex, 10 Mbps Half Duplex, 100 Mbps Full Duplex, and 100 Mbps Half Duplex.
This Allen Bradley 22-COMM-E is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives > Powerflex 4 range and is referenced internally as PartLogic SKU PL26801433695.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | EtherNet/IP Adapter |
| Product Line | PowerFlex 40 |
| Part Number | 22-COMM-E |
| UPC | 820919134623 |
| Weight | 0.13 lbs (0.06 kg) |
| Description | Ethernet I/P communication adapter |
| Compatible Drives | PowerFlex 4, 40 and 400 |
| Communication Port | One (1) RJ45 |
| Communication Protocol | Ethernet I/P |
| Data Rate | 10 Mbps Full Duplex, 10 Mbps Half Duplex, 100 Mbps Full Duplex, and 100 Mbps Half Duplex. |
| No. of TCP connections | 30 TCP connections |
| RPI | 5 ms minimum |
| Packet Rate | Up to 400 total I/O packets per second (200 in and 200 out) |
| Drive Power consumption | 350 mA at 5V DC supplied by the host (drive or DPI External Comms Kit) |
| Operating Temperature | `-10…50 °C (14…122 °F) |
| Storage | -40…85 °C (-40…185 °F) |
| Relative Humidity | 5…95% non-condensing |
| Regulatory Compliance | UL508C, CAN / CSA C22.2 No. 14-M91, EN50178 and EN61800-3, EN61800-3 specifications |
| Status Indicators | 4 LEDs |
| Connection | Ethernet/IP |
| DSI Connector | 20 pins |
| Cable | RJ-45 CAT compliant cable |
| Brand | Allen Bradley |
