Allen Bradley 20P41AD330RA0NNN
The 20P41AD330RA0NNN model from Allen Bradley’s PowerFlex 753 series is classified as a DC drive. It operates with a 3-phase AC system and supports a voltage input range of 380 to 480 volts AC while delivering a normal-duty output power of 200 horsepower. This drive supports various control methods and is rated for a maximum current of 330 Amps.
This Allen Bradley 20P41AD330RA0NNN is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives > Powerflex 4000 range and is referenced internally as PartLogic SKU PL26893875940.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | DC Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20P41AD330RA0NNN |
| UPC | 820919823381 |
| Weight | 65.00 lbs (29.48 kg) |
| Regenerative Drive | Yes |
| Voltage Type | 3-Phase AC |
| Voltage Range | 380-480V AC |
| Frame Size | Size B |
| Current | 330 Amps |
| Normal-Duty Output Power | 200 HP |
| Motor Operation Option | 4-Quadrant Option |
| Process PI Control | Supported |
| Flying Start | Supported |
| Open-Loop Torque Regulation | Supported |
| Closed-Loop Torque Regulation | Supported |
| Open-Loop Speed Regulation | Supported |
| Closed-Loop Speed Regulation | Supported |
| Operating Temperature | 0 to 50 degrees Celsius |
| Brand | Allen Bradley |
