Allen Bradley 20F1AND156JA0NNNNN
The 20F1AND156JA0NNNNN AC drive from Allen Bradley's PowerFlex 753 series is engineered for robust performance. It operates with a rated voltage of 480 VAC across three phases and supports a maximum rated current of 156 A. With a normal duty rating of 125 hp and heavy-duty capabilities of 100 hp, this drive fits diverse applications while ensuring effective cooling through forced air methods.
This Allen Bradley 20F1AND156JA0NNNNN is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives > Powerflex 520 range and is referenced internally as PartLogic SKU PL26988227335.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AND156JA0NNNNN |
| Weight | 150.00 lbs (68.04 kg) |
| Rated Voltage | 480 VAC |
| Number Of Phase | 3-Phase |
| Rated Current | 156 A |
| Normal Duty Horsepower | 125 hp |
| Heavy Duty Horsepower | 100 hp |
| Frame Size | Frame 6 |
| Cooling Method | Forced Air Cooled |
| CM jumper | Installed |
| Temperature Range | 0 to 40°C |
| Max. Storage Humidity | 80% (non-condensing) |
| Max. Operating Humidity | 80% (non-condensing) |
| Max. Operating Altitude | 1000 meters above sea level |
| Brand | Allen Bradley |
