Allen Bradley 20F1AND125JA0NNNNN
The 20F1AND125JA0NNNNN is an Allen Bradley AC drive from the PowerFlex 753 series, designed to function at a rated voltage of 480 VAC in a 3-phase setup. It can handle a rated current of 125 amps and is capable of providing normal duty horsepower up to 100 hp, while also accommodating heavy-duty operations at 75 hp.
This Allen Bradley 20F1AND125JA0NNNNN is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives > Powerflex 520 range and is referenced internally as PartLogic SKU PL26931765813.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F1AND125JA0NNNNN |
| Weight | 125.00 lbs (56.70 kg) |
| Rated Voltage | 480 VAC |
| Number of Phases | 3-Phase |
| Rated Current | 125 A |
| Normal Duty Horsepower | 100 hp |
| Heavy Duty Horsepower | 75 hp |
| Frame Size | Frame 6 |
| Cooling Method | Forced Air Cooled |
| Common Mode (CM) Jumper | Installed |
| Temperature Range | 0 to 40°C |
| Maximum Storage Humidity | 80% (non-condensing) |
| Maximum Operating Humidity | 80% (non-condensing) |
| Maximum Operating Altitude | 1000 meters above sea level |
| Brand | Allen Bradley |
