Allen Bradley 20F11RD5P0AA0NNNNN
The PowerFlex 753 series AC drive, specifically the 20F11RD5P0AA0NNNNN model, is an efficient solution for motor control. Designed with a robust build, it operates at an input voltage of 480 volts AC or 650 volts DC, offering a reliable output current of 5 amps at a power rating of 3 horsepower.
This Allen Bradley 20F11RD5P0AA0NNNNN is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives > Powerflex 520 range and is referenced internally as PartLogic SKU PL26980332605.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F11RD5P0AA0NNNNN |
| UPC | 884951299139 |
| Weight | 5.00 lbs (2.27 kg) |
| Input Type | AC Input with Precharge and DC Terminals |
| Enclosure Type | NEMA/UL Type Open (IP20 class) enclosure |
| Frame Size | 1 |
| Voltage Rating | 480 volts AC / 650 volts DC |
| Output Current (Normal Duty) | 5 amps |
| Power (Normal Duty) | 3 horsepower (HP) |
| Filtering and CM Cap Configuration | Filtered with common mode capacitor jumper removed |
| Dynamic Braking Option | Internal Transistor Included; No Internal Resistor |
| Operator Interface | Blank / No HIM provided |
| Efficiency | 97.5% at rated amps, nominal line volts |
| Operating Temperature | 0 to 50 degrees Celsius (32 to 122 degrees Fahrenheit) |
| Relative Humidity | 5 to 95% non-condensing |
| Storage Temperature | -40 to +70 degrees Celsius (-40 to +158 degrees Fahrenheit) |
| Brand | Allen Bradley |
