Allen Bradley 20F11ND077JA0NNNNN
The Allen Bradley 20F11ND077JA0NNNNN, part of the PowerFlex 753 series, serves as a 3-phase AC drive. It provides a robust output power capacity of 44.7 kilowatts and operates efficiently at 60 horsepower. With a rated current of 77 Amperes, this model supports both AC and DC inputs for versatility.
This Allen Bradley 20F11ND077JA0NNNNN is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Ac drives > Powerflex 520 range and is referenced internally as PartLogic SKU PL26805666666.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | AC Drive |
| Product Line | PowerFlex 753 |
| Part Number | 20F11ND077JA0NNNNN |
| UPC | 889508555430 |
| Weight | 70.00 lbs (31.75 kg) |
| Output Power Rating | 44.7 kilowatts |
| Rated Phase | 3-phase |
| Braking Unit | Internal transistor included |
| Frequency Tolerance | 47 to 63 Hertz |
| Ambient Operating Temperature | 0 to 40°C (in a non-condensing environment) |
| Horsepower Rating | 60 horsepower |
| Voltage Rating | 480 Volts AC and 650 Volts DC |
| Input Type | AC input with precharge and DC terminals |
| Current Rating | 77 Amperes |
| Storage Temperature | -40 to 70°C (in a non-condensing environment) |
| Filtering | Filter included |
| Default Common Mode (CM) Cap Connection | Jumper included |
| Cooling Method | Air cooling |
| User Interface | No Human Interface Module (HIM) |
| Brand | Allen Bradley |
