Allen Bradley 2094-BC04-M03-M
The 2094-BC04-M03-M is an Integrated Axis Module that is part of the Kinetix 6000 Multi-axis servo drive. This module is a 400V class. This module has continuous output power to bus of 13.5 kW. It has a Continuous output current to bus of 21.2 A, Continuous current (sine) 0-pk of 30.0 A, Peak current (rms) of 53.0 A and Peak current (0-pk) of 75.0 A.
This Allen Bradley 2094-BC04-M03-M is supplied brand new by PartLogic for motor control, speed regulation, machinery automation, production equipment and industrial maintenance applications. It forms part of our Industrial automation > Drives > Servo drives > Kinetix 6000 range and is referenced internally as PartLogic SKU PL26944697061.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | Drives |
| Product Line | Kinetix 6200 |
| Part Number | 2094-BC04-M03-M |
| UPC | 884951147799 |
| Weight | 22.00 lbs (9.98 kg) |
| Operating Temperature | 32-122 F (0-50 C) |
| Continuous power output to bus | 27.6kW |
| Continuous output current to bus | 41.5 A |
| AC input Voltage | 324…528V rms,three-phase (360…480V nom) |
| Control Voltage | 95…264V rmss, ingle-phase (110…240V rms nom) |
| Bus overvoltage | 825V DC |
| Bus undervoltage | 275V DC |
| Power Dissipation range | 94-255 Watts |
| Installation Clearance | 50.8 mm (2.0 in.) |
| Minimum Enclosure Depth | 272 mm (10.7 in.) |
| Control Input Fuse | FNQ-R-10 (10 A) or FNQ-R-7.5 (7.5 A) |
| Control Input Breaker | 1492-SPM2D060 or 1492-SPM1D150 |
| DC Bus Power Fuse | Bussmann Fuse : WJ-20A14F Mersen: DCT20-2; HSJ20 |
| Max Bus Capacitance | 8955 Microfarads |
| Power Module | Integrated Axis Module |
| Output Current | 30 Amperes |
| Voltage Rating | 460 Volt (AC) |
| Nom Drive Voltage | 360-480 Volts (3 Phase) |
| Wattage | 13 kWatts |
| Brand | Allen Bradley |
