Allen Bradley 2080-LC20-20QWB
The Allen-Bradley 2080-LC20-20QWB is a is a Micro 820 Programmable Logic Controller (PLC). This controller has Twelve (12) 24VDC. VAC discrete inputs; Seven (7) Relay outputs; Four (4) 0-10V (shared with 24V DC) analog input channels and One (1) 0-10VDC analog output channel. This controller is powered by an external supply voltage of 120VAC , 240VAC. It has One (1) Ethernet I,P communication port and One (1) RS232,485 non-isolated, CIP Serial, Modbus RTU, ASCII communication port.
This Allen Bradley 2080-LC20-20QWB is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Cpu > Micro820 range and is referenced internally as PartLogic SKU PL26801727466.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Programmable Controller |
| Product Line | Micro 820 |
| Part Number | 2080-LC20-20QWB |
| UPC | 885630484648 |
| Weight | 0.63 lbs (0.28 kg) |
| Product Family | Micro 800 |
| Product Description | Micro 820 Programmable Logic Controller (PLC) |
| No. of Inputs | Twelve (12) 24VDC / VAC discrete inputs; |
| No. of Outputs | Seven (7) Relay outputs; |
| No. of Analog inputs | Four (4) 0-10V (shared with 24V DC) |
| No. of Analog outputs | One (1) 0-10VDC |
| Communication ports | One (1) Ethernet; One (1) RS232; One (1) USB |
| Plug-in slots | 2 |
| Program Steps (or instructions) | 10Ksteps |
| Data (bytes) | 20Kbytes (up to 400bytes non-volatile) |
| IEC 61131-3 Languages | Ladder Diagram, Function Block, Structured Text |
| Inputs | 12(24V DC) |
| Outputs | 7(Relay); 1 (Analog Out) |
| Power Input | 24V DC |
| Power Dissipation | 6 W |
| Power Supply Voltage Range | 20.4-26.4V DC, Class 2 |
| Enclosure | Meets IP20 |
| Non-Isolated DC Input On-state Voltage Range | 9.8-26.4V DC |
| Relay Output Voltage min. | 5V DC/ AC |
| Relay Output Voltage max. | 250V AC |
| Pilot Duty Rating | C300, R150 |
| Terminal Block | Fixed |
| Brand | Allen Bradley |
