Allen Bradley 2080-LC20-20AWB
The 2080-LC20-20AWB is a Micro 820 Programmable Logic Controller (PLC). This controller is part of the Micro 800 series that is manufactured by Allen-Bradley. This controller is designed for use in micro or small automation requirements, featuring One (1) USB 2.0 configuration and programming port; One (1) Ethernet port supporting 10,10 Mbps transmission rate, and One (1) RS232 , 485 combo port. This controller has built-in Eight (8) 120 VAC, Four (4) 24VDC , VAC, Four (4) 0-10 VDC analog inputs that are shared with 24 VDC; Seven (7) Normally Open (N.O.) relay outputs and Seven (7) 24 VDC sourcing outputs and One (1) 0-10 VDC analog output channel.
This Allen Bradley 2080-LC20-20AWB is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Cpu > Micro820 range and is referenced internally as PartLogic SKU PL26801377535.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Programmable Controller |
| Product Line | Micro 820 |
| Part Number | 2080-LC20-20AWB |
| UPC | 885630484655 |
| Weight | 0.56 lbs (0.26 kg) |
| Inputs | 8 (120 Volts AC); 4 (24 Volt DC) |
| Outputs | 7(Relay); 1 (Analog Out) |
| Product Description | Programmable Logic Controller (PLC) |
| Integrated discrete inputs | Eight (8) 120 VAC; Four (4) 24VDC / VAC |
| Power Input | 24 Volts DC |
| Integrated sourcing outputs | Seven (7) 24 VDC sourcing outputs |
| Power Dissipation | 6 Watts |
| Integrated Relay outputs | Seven (7) Normally Open (N.O.) relay outputs |
| Power Supply Voltage Range | 20.4 to 26.4 Volts DC, Class 2 |
| Integrated Analog input | Four (4) 0-10 VDC analog inputs that is shared with 24 VDC; |
| Enclosure | IP20 |
| Integrated Analog output | One (1) 0-10 VDC analog output channel |
| AC Input Voltage maximum | 125 Volts AC |
| Built-in communication interfaces | One (1) USB 2.0; One (1) RS232 / RS485 combo port One (1) Ethernet Class 3 |
| Relay Output Voltage minimum | 5 Volts AC/DC |
| Supported Protocols | Modbus TCP, Modbus RTU Master/Slave, ASCII, CIP |
| Relay Output Voltage maximum | 250 Volts AC |
| Maximum number of steps | 10K Steps |
| Pilot Duty Rating | C300, R150 |
| Maximum data size | 20K bytes |
| Terminal Block | Fixed |
| Floating Point Math | Supported |
| PID control | Supported |
| User defined blocks | Supported |
| Brand | Allen Bradley |
