Allen Bradley 1794-VHSC
The Allen-Bradley 1794-VHSC Flex I,O Very High Speed Counter Module has 2 Input Channels, 2 Groups of 3 Inputs per Counter, and a 5V DC Input Voltage. It also operates with a 5mA Input On-state Current.
This Allen Bradley 1794-VHSC is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Specialty range and is referenced internally as PartLogic SKU PL26986844743.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Very High Speed Counter Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-VHSC |
| UPC | 612598205493 |
| Weight | 0.25 lbs (0.11 kg) |
| Input Channels | 2 |
| Inputs per Counter | 2 Groups of 3 |
| Input Voltage | 5V DC |
| Input Off-state Voltage | \u003C1.8V DC |
| Input Off-state Current | \u003C0.25 mA |
| Input On-state Current | >5mA |
| Outputs | 2 Isolated Groups of 2 |
| Output Supply Voltage Range | 10-31V DC |
| Power Dissipation | 5.0W @ 31.2V DC max. |
| Thermal Dissipation | 17.1 BTU/hr. @ 31.2V DC max. |
| Brand | Allen Bradley |
