Allen Bradley 1794-OE4
The Allen-Bradley 1794-OE4 is a Flex I,O analog output module. This module has Four (4) analog output channels, providing analog output signals such as 0 to 20 mA; 4 to 20 mA; +,- 10VDC; 0 to 10 VDC. It has a resolution of 12-bit and compatible for installation with terminal bases such as 1794-TB2, -TB3, -TB3S, -TB3T, -TB3TS, and -TBN.
This Allen Bradley 1794-OE4 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog output range and is referenced internally as PartLogic SKU PL26805525199.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Output Analog Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-OE4 |
| GTIN | 10612598137876 |
| Weight | 0.25 lbs (0.11 kg) |
| Conversion Type | Pulse Width modulation |
| Data Format | left justified, 16 bit 2s complement |
| Resolution | 12 bits plus sign Voltage: 2.56mV/cnt Current: 5.13µA/cnt |
| Product Description | Flex IO High Density Analog Output Module |
| No. of inputs | Four (4) Single Ended |
| Output type | 0 to 20 mA; 4 to 20 mA; +/- 10VDC; 0 to 10 VDC |
| Conversion Rate | 1.024ms maximum all channels |
| Terminal base | 1794-TB2, -TB3, -TB3S, -TB3T, -TB3TS, and -TBN |
| Indicators | 1 green/red power/status indicator |
| External DC supply, nom | 24V DC |
| External DC supply range | 10.0…31.2V DC (includes 5% AC ripple) |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | –40…85 °C (–40…185 °F) |
| Vibration | 5g @ 10 to 500 Hz |
| Outputs | 4 Single-ended |
| Output Current Terminal | 4 to 20 mA |
| Output Voltage Terminal | +/- 10 Volts |
| Current Load on Voltage Output | 3 mA maximum |
| Flexbus Current | 20 mA |
| Power Dissipation | 4.5 W at 31.2 Volts DC maximum |
| Thermal Dissipation | 13.6 BTU/hour at 31.2 Volts DC maximum |
| UPC | 10612598137876 |
| UNSPSC | 32151602 |
| Brand | Allen Bradley |
