Allen Bradley 1794-OE12
The Allen-Bradley 1794-OE12 is a Flex IO analog output module. This module features Twelve (12) single-ended, non-isolated Voltage, Current analog output channels. It delivers output current signals such as 4-20 mA, 0-20 mA and Voltage signals such as ±10VDC. It is compatible with a terminal bases such as 1794-TB3G or 1794-TB3GS. It is compatible with any 1794 Flex IO adapters to implement distributed I,O application.
This Allen Bradley 1794-OE12 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog output range and is referenced internally as PartLogic SKU PL26933364210.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Analog Output Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-OE12 |
| UPC | 612598320196 |
| Weight | 0.25 lbs (0.11 kg) |
| Flexbus Current | 80 mA |
| Product Description | Flex IO High Density Analog Output Module |
| No. of outputs | Twelve (12) Single Ended |
| Output type | 0 to 20 mA; 4 to 20 mA; +/- 10VDC; |
| Conversion Type | Digital to Analog Converter |
| Resolution | 16 bit 2’s complement, left justified |
| Terminal base | 1794-TB3G; 1794-TB3GS |
| Indicators | 1 green/red power/status indicator |
| External DC supply, nom | 24V DC |
| External DC supply range | 10.0…31.2V DC (includes 5% AC ripple) |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | –40…85 °C (–40…185 °F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
| Outputs | 12 Single-ended |
| Output Voltage Range | +/-10V |
| Output Current | 0-20mA max. |
| Voltage Output Current Load | 3mA max. |
| Voltage Resolution | 320 ?V/cnt |
| Current Resolution | 0.641 ?A/cnt |
| Resistive Load, mA Output | 0750 ? @ 24V DC |
| Power Dissipation | 4.0W @ 31.2V DC |
| Thermal Dissipation | 4.7 BTU/hr. @ 24V DC |
| Brand | Allen Bradley |
