Allen Bradley 1794-OB16P
The Allen-Bradley 1794-OB16P is a Flex I,O discrete output module. This module has Sixteen (16) Current sourcing outputs, providing 24VDC voltage output. Each channel of this module are electronically protected. Compatible terminal bases for this module are 1794-TB2,1794-TB3,1794-TB3S, 1794-TB3K, 1794-TB3SK.
This Allen Bradley 1794-OB16P is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output range and is referenced internally as PartLogic SKU PL27204939221.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Digital DC Output Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-OB16P |
| UPC | 612598179961 |
| Weight | 0.19 lbs (0.09 kg) |
| Flexbus Current | 60 mA @ 5V DC |
| Power Dissipation | 5.0 W @ 31.2V DC |
| Thermal Dissipation | 17.0 BTU/hr @ 31.2V DC |
| Product Description | Flex IO 24VDC Output Module |
| Number of Inputs | 16, sourcing; electronically fused |
| Terminal base | 1794-TB2, 1794-TB3, 1794-TB3S, 1794-TBKD |
| ON state Voltage, min | 10VDC |
| ON state Voltage, max. | 31.2VDC |
| ON state Voltage, nom | 24VDC |
| Indicators | 16 Yellow status indicators |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
| Outputs | 16 Sourcing Current |
| Output Current Rating | 8.0A |
| On-state Current max. | 500mA per Channel |
| On-state Voltage Drop max. | 0.5V DC |
| Off-state Leakage Current max. | 0.5mA |
| Isolation Voltage | 50V Continuous |
| Brand | Allen Bradley |
