Allen Bradley 1794-OB16
The Allen-Bradley 1794-OB16 is a Flex IO discrete output module. This module features Sixteen (16) 24VDC sourcing output channels. It is compatible with a variety of terminal base units such as 1794-TB2, 1794-TB3, 1794-TB3S,1794-TB3K, 1794-TB3SK. It is compatible with any 1794 Flex IO adapters to implement distributed I,O application.
This Allen Bradley 1794-OB16 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output range and is referenced internally as PartLogic SKU PL26801430092.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Digital DC Output Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-OB16 |
| GTIN | 10612598137852 |
| Weight | 0.25 lbs (0.11 kg) |
| Product Description | Flex IO DC Output Module |
| Number of Outputs | 16, sourcing |
| Terminal base | 1794-TB2,1794-TB3,1794-TB3S, 1794-TB3K, 1794- TB3SK |
| ON state Voltage, min | 10VDC |
| ON state Voltage, max. | 31.2VDC |
| ON state Voltage, nom | 24VDC |
| Indicators | 16 Yellow status indicators |
| Keyswitch position | 2 |
| Enclosure | Open-type |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
| Outputs | 16 Sourcing Current |
| Output Current Rating | 8.0A |
| On-state Current max. | 500mA per Channel |
| On-state Voltage Drop max. | 0.5V DC |
| Off-state Leakage Current max. | 0.5mA |
| Isolation Voltage | 50V Continuous |
| Flexbus Current | 80mA @ 5V DC |
| Power Dissipation | 5.3W @ 31.2V DC max. |
| Thermal Dissipation | 18.1 BTU/hr. @ 31.2V DC max. |
| UPC | 10612598137852 |
| Brand | Allen Bradley |
