Allen Bradley 1794-OA16
The Allen-Bradley 1794-OA16 is a Flex IO AC digital output module. This module features Sixteen (16) non-isolated output channels with output voltage range of 74-132VAC. It is compatible with a variety of terminal bases such as 1794-TBN, 1794-TBNF, 1794-TB2, 1794-TB3, 1794-TB3S, 1794-TBKD, 1794-TBNK, 1794-TBNFK, 1794-TB3K, 1794-TB3SK. It is compatible with any 1794 Flex IO adapters to implement distributed I,O application.
This Allen Bradley 1794-OA16 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output range and is referenced internally as PartLogic SKU PL26805526487.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Digital Output Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-OA16 |
| UPC | 612598179947 |
| Weight | 0.25 lbs (0.11 kg) |
| Product Description | Flex IO AC Output Module |
| Number of Outputs | 16, non-isolated |
| Terminal base | 1794-TBN, 1794-TBNF, 1794-TB2, 1794-TB3, 1794-TB3S, 1794-TBKD, 1794-TBNK, 1794-TBNFK, 1794-TB3K, 1794-TB3SK. |
| ON state Voltage, min | 74VAC |
| ON state Voltage, max. | 120VAC |
| ON state Voltage, nom | 132VAC |
| Pilot duty rating | 5A inrush |
| External AC Power supply | 120 VAC |
| Indicators | 16 Yellow status indicators |
| Keyswitch position | 8 |
| Enclosure | Open-type |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | 5g @ 10 to 500 Hz |
| Outputs | 16 Nonisolated |
| Output Voltage nom. | 120 Volts AC |
| Output Current Rating | 4.0 Amps |
| On-state Current min. | 5 mA per Output |
| On-state Voltage Drop max. | 1.5 Volts AC at 0.5 Amps |
| Off-state Leakage Current max. | 2.25 mA |
| Isolation Voltage | 120 Volts Continuous |
| Flexbus Current | 80 mA at 5 Volts DC |
| Power Dissipation | 4.7 W at 0.5 Amps maximum |
| Thermal Dissipation | 16.1 BTU/hour at 0.5 Amps maximum |
| Brand | Allen Bradley |
