Allen Bradley 1794-IE4XOE2
The Allen-Bradley 1794-IE4XOE2 is a Flex IO combination analog I,O module. This module features Four (4) single-ended, non-isolated Current and voltage analog input channels configurable for 0-20 and 4-20 mA and +,-10VDC and 0-10 VDC, respectively. It also has Two (2) single-ended non-isolated analog output channels configurable for 0-20 and 4-20 mA and +,- 10VDC. This module requires use of 1794-TB2, -TB3, -TB3S, -TB3T, -TB3TS Terminal Base Units.
This Allen Bradley 1794-IE4XOE2 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Combination range and is referenced internally as PartLogic SKU PL26948375309.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O High-Density Analog Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IE4XOE2 |
| UPC | 612598137800 |
| Weight | 0.31 lbs (0.14 kg) |
| Resolution | 12 bit plus sign |
| Conversion Type | Pulse Width Modulation (PWM) |
| Product Description | Flex IO combination analog I/O module |
| No. of inputs | Four (4) single-ended, non-isolated inputs |
| Current input signals | 0-20 mA / 4-20 mA |
| Input resolution | 12 bits unipolar / 11 bits plus sign bipolar |
| No. of outputs | Two (2) Single Ended, non-isolated |
| Output type | 0 to 20 mA; 4 to 20 mA; +/- 10VDC; |
| Terminal base | 1794-TB2, -TB3, -TB3S, -TB3T, -TB3TS |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Storage Temperature | –40…85 °C (–40…185 °F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
| Inputs | 4 Single-ended |
| Input Current Terminal | 4-20mA |
| Input Voltage Terminal | +/- 10V |
| FlexBus Current | 20mA |
| Outputs | 2 Single-ended |
| Output Current Terminal | 4-20mA |
| Output Voltage Terminal | +/- 10V |
| Thermal Dissipation | 10.2 BTU/hr. @ 31.2V DC max. |
| Brand | Allen Bradley |
