Allen Bradley 1794-IE12
The Allen-Bradley 1794-IE12 is a Flex I,O High density analog input module. It has Twelve (12) Voltage , Current single-ended input channels. It is compatible for use with Flex I,O communication adapters and installed to terminal bases such as 1794-TB3G or 1794-TB3GS.
This Allen Bradley 1794-IE12 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog input range and is referenced internally as PartLogic SKU PL26801442615.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O High-Density Analog Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IE12 |
| UPC | 612598320172 |
| Weight | 0.38 lbs (0.17 kg) |
| Conversion Rate | 8.0 ms all channels |
| Product Description | Flex IO High Density Analog Input Module |
| No. of inputs | Twelve (12) Single Ended |
| Input type | 0 to 20 mA; 4 to 20 mA; +/- 10VDC; 0 to 10 VDC |
| Conversion Type | Successive Approximation |
| Resolution | 16 bit 2’s complement, left justified Voltage: 320 ?V/cnt Current: 0.641 ?A/cnt |
| Absolute Accuracy | 0.1% full scale @ 25 °C |
| Terminal base | 1794-TB3G; 1794-TB3GS |
| Indicators | 1 green/red power/status indicator |
| External DC supply, nom | 24V DC |
| External DC supply range | 10.0…31.2V DC (includes 5% AC ripple) |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | –40…85 °C (–40…185 °F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
| Inputs | 12 Single-ended |
| Resolution Voltage Current | 320 ?V/cnt |
| Input Current Terminal | 4-20mA |
| Input Voltage Terminal | +/- 10V |
| FlexBus Current | 80 mA |
| External DC Power Supply | 24V DC nom. |
| Isolation Voltage | 50V Continuous |
| Power Dissipation | 1.2W @ 31.2V DC max. |
| Thermal Dissipation | 4.1 BTU/hr. @ 31.2V DC max. |
| Brand | Allen Bradley |
