Allen Bradley 1794-IB32
The Allen-Bradley 1794-IB32 is a Flex I,O DC input module. This module has Thirty-Two (32) current, sinking input channels with input voltage range of 19.2-31.2VDC. It is compatible for use with Flex I,O communication adapters and terminal bases such as 1794-TB32, 1794-TB32S, 1794-TB62DS, 1794-TB62EXD4X15.
This Allen Bradley 1794-IB32 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital input range and is referenced internally as PartLogic SKU PL26805637754.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O Digital Input Modules |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IB32 |
| UPC | 612598279906 |
| Weight | 0.25 lbs (0.11 kg) |
| Product Family | Flex I/O |
| Product Description | Flex IO DC Input Module |
| Number of Inputs | Thirty-Two (32), sinking inputs |
| Terminal base | 1794-TB3, 1794-TB3S ,1794-TBN, 1794-TB3K, 1794-TB3SK and 1794-TBNK |
| Keyswitch Position | 2 |
| ON state Voltage, min | 10VDC |
| ON state Voltage, max. | 31.2VDC |
| OFF state Voltage, max | 24VDC |
| Indicators | 32 Yellow status indicators |
| Mounting | DIN Rail |
| Wire Size | Determined by installed terminal base |
| Enclosure type rating | None (open-style) |
| Operating Temperature | 0 to 55 C (32 to 131 F) |
| Storage Temperature | -40 to 85 C (-40 to 185 F) |
| Vibration | 5g @ 10 to 500 Hz |
| Operating Shock | 30 g |
| Inputs | 32 Current Sinking |
| On-state Current (minimum) | 2.0 milliamps |
| On-state Current (maximum) | 6.0 milliamps |
| Off-state Voltage (maximum) | 5 Volts DC |
| Off-state Current (maximum) | 1.5 milliamps |
| Nominal Input Impedance | 22.2 k? |
| Flexbus Current | 30 milliamps at 5 Volts DC |
| Power Dissipation | 6.0 Watts at 31.2 Volts DC maximum |
| Brand | Allen Bradley |
