Allen Bradley 1794-IA8
The Allen-Bradley 1794-IA8 input module is a discrete input module with 8 inputs. It is part of the Flex I,O 1794 series. The 1794-IA8 input module is an AC-powered input module with a nominal voltage rating of 120 Volts AC. It is an open-style module with an IP 20 environmental protection rating that mounts on a DIN Rail. The 1794-IA8 input module?s 8 inputs are not isolated from each other.
This Allen Bradley 1794-IA8 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital input range and is referenced internally as PartLogic SKU PL27209213725.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Flex I/O AC Digital Input Module |
| Product Line | Flex I/O 1794 |
| Part Number | 1794-IA8 |
| UPC | 612598137763 |
| Weight | 0.25 lbs (0.11 kg) |
| Inputs | 8 Non-Isolated |
| On-state Voltage min. | 65V AC |
| On-state Voltage max. | 132V AC |
| On-state Current min. | 7.1mA |
| On-state Current max. | 14.32mA |
| Off-state Voltage max. | 43V AC |
| Off-state Current min. | 2.9mA |
| Nominal Input Current | 12 mA @ 120V AC |
| Flexbus Current | 30mA @ 5V DC |
| Power Dissipation | 4.5W @ 132V AC max. |
| Brand | Allen Bradley |
