Allen Bradley 1769-OW8I
The 1769-OW8I is Compact I,O expansion module. This module has Eight (8) individually isolated Form A Relay output channels. It has Two (2) groups of Four (4) channels each. This module is designed for an operating voltage range of 5 - 265VAC and 5 - 125V DC. It is compatible for use with MicroLogix 1500 and CompactLogix controllers.
This Allen Bradley 1769-OW8I is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Compactlogix range and is referenced internally as PartLogic SKU PL26805524350.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Discrete Output Module |
| Product Line | CompactLogix |
| Part Number | 1769-OW8I |
| UPC | 662468992916 |
| Weight | 0.50 lbs (0.23 kg) |
| Product Family | Compact I/O |
| Module Type | Output Module |
| No. of outputs | Eight (8) Individually Isolated |
| Input Type | Relay Output |
| Power Supply Distance rating | 8 |
| I/O Type | Contact |
| Compatible controllers | MicroLogix 1500; CompactLogix controllers |
| Communication Cable | 8 Point |
| Voltage Category | AC/DC normally open relay |
| Operating Voltage range | 5 to 265V ac 5 to 125V dc |
| Signal delay, On | 10 ms |
| Series | A and B |
| Wire Type | Copper 90 degrees |
| Bus Current draw, 5.1 V | 125 mA |
| Solid Wire Size | 22 to 14 AWG |
| Bus Current draw, 24 V | 100 mA |
| Stranded Wire Size | 22 to 16 AWG |
| Heat Dissipation | 2.83 Watts |
| Slot width | 1 |
| UNSPSC | 32151705 |
| Mounting | DIN Rail or Panel Mount |
| Power Supply | 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4 |
| Wire Size | (22…14 AWG) solid (22…16 AWG) stranded |
| Brand | Allen Bradley |
