Allen Bradley 1769-OV16
The 1769-OV16 is a discrete output module that is part of Allen-Bradley’s Compact I,O controller platform. This module features Sixteen (16) channels providing 24 VDC output voltage in sink wiring configuration. Each channel has a voltage output range of 20.4 - 26.4 VDC with current output of 0.5 A @ 60 °C (140 °F) and 1.0 A @ 30 °C (86 °F) per channel.
This Allen Bradley 1769-OV16 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Compactlogix range and is referenced internally as PartLogic SKU PL27214089271.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | CompactLogix |
| Part Number | 1769-OV16 |
| UPC | 662468992886 |
| Weight | 0.44 lbs (0.20 kg) |
| Series | Compact I/O |
| No. of Outputs | Sixteen (16) outputs |
| No. of Channels | Sixteen (16) |
| No. of groups | One (1) output group |
| Wiring configuration | Sink |
| Module Type | 24 VDC Discrete output module |
| Output Voltage | 24 VDC output |
| Output voltage range | 20.4 - 26.4 VDC |
| Input Type | Sinking Output |
| Operating Voltage Range | 20.4-26.4 VDC |
| Output Current per point | 0.5 A @ 60 °C (140 °F); 1.0 A @ 30 °C (86 °F) |
| Output Delay Time, ON | 0.1 ms |
| Output Current per module | 4.0 A @ 60 °C (140 °F); 8.0 A @ 30 °C (86 °F) |
| Communication Cable | 16 Point |
| Output Delay Time, OFF | 1.0 ms |
| Surge current | 2.0 A for 10 ms, repeatable every 2 s |
| OFF state leakage current | 1.0 mA @ 26.4 VDC |
| Resolution | 14 bits across 21V (1.3 mV); 13 bits across 10.5V +sign bit |
| Backplane Current at 5.1 Volts | 200 mA |
| Output delay, ON | 0.1 ms |
| Continuous current per point | 0.5 A @ 60 degrees C (140 degrees F); 1.0 A @ 30 degrees C (86 degrees F); |
| Output delay, OFF | 1.0 ms |
| Enclosure | Open |
| Continuous current per module, max | 4.0 A @ 60 degrees C (140 degrees F); 8.0 A @ 30 degrees C (86 degrees F). |
| Backplane Current draw @ 5.1V | 200 mA |
| Wire Type | Copper-90 |
| Compatible Controllers | MicroLogix 1500; CompactLogix |
| Solid Wire Size | 22-14 AWG |
| Stranded Wire Size | 22-16 AWG |
| Brand | Allen Bradley |
