Allen Bradley 1769-OF4CI
The Allen-Bradley 1769-OF4CI is Compact I,O module. This module is an analog output module with Four (4) differential, individually isolated channels configurable for Current signals. Applicable output current range are 0-20 mA or 4-20 mA. Output signals may be used to drive modulating actuators and devices. This module is compatible for use with MicroLogix 1500 and CompactLogix controllers.
This Allen Bradley 1769-OF4CI is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Analog output > Compactlogix range and is referenced internally as PartLogic SKU PL26805609967.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | CompactLogix |
| Part Number | 1769-OF4CI |
| UPC | 781180908651 |
| Weight | 0.56 lbs (0.26 kg) |
| Product Family | Compact I/O |
| Module Type | Analog Output Module |
| Power Supply Distance Rating | 8 |
| No. of outputs | Four (4) Differential; Individually isolated |
| Communication Cable | 4 Point |
| Compatible controllers | MicroLogix 1500; CompactLogix controllers |
| Series | A and B |
| Analog Ranges | Current: 0 to 20 mA, 4 to 20 mA |
| Full scale analog ranges | Current: 0 - 21 mA, 3.2 - 21 mA |
| Field Calibration | None Required |
| Analog data format | Raw / Proportional data, Engineering unit, Scaled for PID and Percent full range. |
| Replacement Door Part Number | 1769-RD |
| Conversion rate | 110 ms |
| Wire Type | Copper-90 AWG |
| Digital resolution | 16 bits (unipolar) +4 to +20 mA: 15.59 bits, 0.323 µA/bit 0 to +20 mA: 15.91 bits, 0.323 µA/bit |
| Solid Wire Size | 22 to 14 AWG |
| Calibration | None required (guaranteed by hardware design) |
| Stranded Wire Size | 22 to 16 AWG |
| Non-linearity (in percent full scale) | ±0.05% |
| UNSPSC | 32151705 |
| Slot width | 1 |
| Power Supply | 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4 |
| Recommended cable | Belden 8761 (shielded) |
| Module location | DIN rail or panel mount |
| Brand | Allen Bradley |
