Allen Bradley 1769-OB16P
The Allen-Bradley 1769-OB16P is a 1769 Compact I,O Solid-state 24VDC output module. This module features Sixteen (16) protected output channels in a single group. It delivers 20.4-26.4VDC output voltage range. This module is compatible for use with the CompactLogix and MicroLogix 1500 controllers.
This Allen Bradley 1769-OB16P is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Compactlogix range and is referenced internally as PartLogic SKU PL26801426225.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | CompactLogix |
| Part Number | 1769-OB16P |
| UPC | 662468992879 |
| Weight | 0.38 lbs (0.17 kg) |
| Series | 1769 Compact I/O |
| Module Type | Solid-state DC Output Module |
| No. of Outputs | Sixteen (16) outputs |
| Electronic Protection | Integrated |
| No. of groups | One (1) output groups |
| Output Voltage | 24VDC |
| Operating Voltage Range | 20.4-26.4VDC |
| Output Delay Time, OFF to ON | 1 ms |
| Output Delay Time, ON to OFF | 2 ms |
| OFF state leakage current | 1.0 mA @ 26.4V DC |
| Backplane Current at 5.1 Volts | 160 mA |
| Continuous current per point | 0.50 A @ 30 °C (30 °C) 1.0 A @ 55 °C (60 °C) |
| Continuous current per module, max | 4.0 A @ 30 °C (30 °C) 8.0 A @ 55 °C (60 °C) |
| Input Type | Digital Output |
| Communication Cable | 16-Point |
| Power | 24 Volts DC |
| Power Supply Distance Rating | 8 Modules |
| Voltage Category | 100 to 240 Volts AC |
| Wire Size (Solid) | 22 to 14 AWG |
| UNSPSC | 32151705 |
| Brand | Allen Bradley |
