Allen Bradley 1769-OA8
The 1769-OA8 is a CompactLogix Discrete output module which operate at a voltage category of 85 to 265V AC at a frequency of 47 to 63 Hz. This module has Eight (8) outputs with Two (2) groups of Four (4) channels each. This module is compatible for use with a 1769 CompactLogix chassis or MicroLogix 1500.
This Allen Bradley 1769-OA8 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Compactlogix range and is referenced internally as PartLogic SKU PL26801466702.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | Compact I/O |
| Product Line | CompactLogix |
| Part Number | 1769-OA8 |
| UPC | 662468992848 |
| Weight | 0.44 lbs (0.20 kg) |
| Module Type | Output Module |
| Input Type | Analog Output |
| Compatible Controllers | MicroLogix 1500; 1769 CompactLogix |
| No. of Inputs | 8 |
| Power Supply Distance Rating | 8 |
| Communication Cable | 8 Point |
| No. of Groups | 2 groups (4 inputs each) |
| Voltage Category | 120-240 VAC |
| Series | A and B |
| Operating Voltage range | 85V ac to 265VAC |
| Operating frequency | 47 to 63 Hz |
| Signal delay | Turn-on = 1/2 cycle turn-off = 1/2 cycle |
| Wire Size (Solid) | 22 o 14 AWG |
| Bus Current draw, max | 145 mA at +5V dc line (1.125W) |
| Wire Size (Stranded) | 22 to 16 AWG |
| Heat Dissipation | 2.12 Watts |
| Wire size | (22…14 AWG) solid (22…16 AWG) stranded |
| Mounting | DIN Rail; Panel Mount |
| Power supply | 1769-PA2, 1769-PB2, 1769-PA4, 1769-PB4 |
| Brand | Allen Bradley |
