Allen Bradley 1769-OA16
The Allen-Bradley 1769-OA16 is a 1769 Compact I,O Discrete AC output module. This module features Sixteen (16) AC output channels in Two (2) groups of Eight (8) outputs each channel. It delivers 120 VAC , 240 VAC nominal voltage output within voltage range of 85-264 VAC, 47-63 Hz. This module is compatible for use with the CompactLogix and MicroLogix 1500 controllers.
This Allen Bradley 1769-OA16 is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Io modules > Digital output > Compactlogix range and is referenced internally as PartLogic SKU PL26801461983.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Category | PLCs |
| Product Line | CompactLogix |
| Part Number | 1769-OA16 |
| UPC | 612598286225 |
| Weight | 1.00 lbs (0.45 kg) |
| Module Type | Digital AC Output Module |
| Series | 1769 Compact I/O |
| No. of Outputs | Sixteen (16) outputs |
| No. of groups | Two (2) output groups |
| Output Voltage | 120/240 VAC output |
| Operating Voltage Range | 85-264 VAC |
| Output Delay Time, OFF to ON | ½ cycle |
| OFF state leakage current | 2.0 mA @ 132V AC 2.5 mA @ 265V AC |
| Backplane Current at 5.1 Volts | 225 mA |
| Continuous current per point | 0.50 A @ 30 °C (30 °C) 0.25 A @ 55 °C (60 °C) |
| Continuous current per module, max | 2.0 A @ 30 °C (30 °C) 4.0 A @ 55 °C (60 °C) |
| Communication Cable | 16-Point |
| Wire Type | Copper 90 degrees Celsius |
| Enclosure | Open |
| Power Supply Distance Rating | 8 Modules |
| Voltage Category | 100 to 240 Volts AC |
| Wire Size (Solid) | 22-14 AWG |
| Wire Size (Stranded) | 22-16 AWG |
| UNSPSC | 32151705 |
| Brand | Allen Bradley |
