Allen Bradley 1769-L19ER-BB1B
The Allen-Bradley 1769-L19ER-BB1B is a CompactLogix 5370 Programmable Automation Controller (PAC) series. This controller features dual Ethernet interfaces functioning as a built-in ethernet switch supporting linear and redundant Ethernet I,P topology. This series of controllers have 1 MB user memory, that is shipped with a 1784-SD1 memory card. It has 1 USB communication port and supports handling up to 32 controller tasks with 100 programs for each task. This controller comes with embedded 16 24 VDC discrete inputs and 16 24VDC Discrete outputs and supports installation of up to Six (6) 1734 POINT I,O expansion I,O modules.
This Allen Bradley 1769-L19ER-BB1B is supplied brand new by PartLogic for machine control, process automation, industrial communication, equipment maintenance and replacement applications. It forms part of our Industrial automation > Plc controllers > Cpu > Compactlogix range and is referenced internally as PartLogic SKU PL26805661600.
Before ordering, please confirm the manufacturer part number, product specifications and compatibility with your existing equipment. If you are replacing a failed, obsolete or hard-to-find part, contact PartLogic and we can help check suitability or source related components.
| Manufacturer | Allen Bradley |
| Product Type | CompactLogix Controller |
| Product Line | CompactLogix |
| Part Number | 1769-L19ER-BB1B |
| UPC | 887172807770 |
| Weight | 1.69 lbs (0.77 kg) |
| Product Family | 5370 L1 |
| Communication ports | (1) USB; (2) Ethernet I/P |
| Ethernet topologies | Linear, Star and Device level Ring (DLR) |
| Ethernet nodes | 8 Nodes |
| User memory | 1 MB |
| Non-volatile memory | 1GB (replaceable) |
| Maximum number of I/O modules supported | 8 Modules - Point I/O |
| No. of Task | 32 Task |
| No. of Program per Task | 100 |
| No. of Embedded Inputs | (16) 24 VDC |
| Programming Language | Relay ladder (Safety Task only) • Structured Text • Function block • SFC |
| Mounting | DIN Rail |
| Current draw @ 5V DC | 1A |
| Series | CompactLogix 5370 |
| Module Type | Processor Module |
| Communication | Ethernet |
| Input Power | 24VDC |
| No. of tasks | 32 |
| Memory | 1MB |
| Programs per task | 100 programs |
| Event Triggers | All triggers |
| No. of embedded I/Os | 16 Discrete inputs; 16 Discrete outputs |
| Built-in communication | 1 USB port; Two (2) Ethernet ports |
| Replacement Terminal Block Part Number | 1769-RTBN18 |
| Supported topologies | Linear; Device Level Ring (DLR) |
| Wire Type | Copper-90 degrees Celsius |
| Ethernet data rate | 10/100 mbps |
| Wire Size (Solid) | 22-14 AWG |
| USB data rate | 12 mbps |
| Wire Size (Stranded) | 22-16 AWG |
| No. of expansion modules | Eight (8) 1734 POINT I/O modules |
| No. of I/O Banks supported | None |
| Brand | Allen Bradley |
